Würth Elektronik 824012823
Images are for reference only
Manufacturer
Manufacturer No
824012823
Date Code
22+
Quantity
1,000
Availability
In Stock
Package
6-XFDFN
Packaging
Tape & Reel (TR); Cut Tape (CT)
Description
TVS DIODE 3.3VWM 13VC DFN1210-6
Detailed Description
13V (Typ) Clamp 3A (8/20µs) Ipp Tvs Diode Surface Mount DFN1210-6
Datasheet
Payment
Delivery
Mfr
Würth Elektronik
Type
Steering (Rail to Rail)
Series
WE-TVS
Packaging
Tape & Reel (TR); Cut Tape (CT)
Applications
General Purpose
Mounting Type
Surface Mount
Package / Case
6-XFDFN
Power - Peak Pulse
-
Operating Temperature
-55°C ~ 85°C (TA)
Power Line Protection
No
Capacitance @ Frequency
0.18pF @ 1MHz
Supplier Device Package
DFN1210-6
Unidirectional Channels
2
Voltage - Breakdown (Min)
4.5V
Voltage - Clamping (Max) @ Ipp
13V (Typ)
Voltage - Reverse Standoff (Typ)
3.3V (Max)
Current - Peak Pulse (10/1000µs)
3A (8/20µs)
| Attribute | Value |
|---|---|
| Mfr | Würth Elektronik |
| Type | Steering (Rail to Rail) |
| Series | WE-TVS |
| Packaging | Tape & Reel (TR); Cut Tape (CT) |
| Applications | General Purpose |
| Mounting Type | Surface Mount |
| Package / Case | 6-XFDFN |
| Power - Peak Pulse | - |
| Operating Temperature | -55°C ~ 85°C (TA) |
| Power Line Protection | No |
| Capacitance @ Frequency | 0.18pF @ 1MHz |
| Supplier Device Package | DFN1210-6 |
| Unidirectional Channels | 2 |
| Voltage - Breakdown (Min) | 4.5V |
| Voltage - Clamping (Max) @ Ipp | 13V (Typ) |
| Voltage - Reverse Standoff (Typ) | 3.3V (Max) |
| Current - Peak Pulse (10/1000µs) | 3A (8/20µs) |
