Analog Devices Inc. PE1V34001

Images are for reference only

Manufacturer

Analog Devices Inc.

Manufacturer No

PE1V34001

Package

Module Adapter, SMA F (2)

Packaging

Bulk

Description

PLL FREQUENCY SYNTHESIZER

Detailed Description

7.5GHz Center Frequency 0 V ~ 20 V Voltage Controlled Oscillator 17 dBm -15 2nd Harmonic Typ (dBc)

Datasheet

PE1V34001

Payment

Delivery

Height

0.291" (7.38mm)

Series

-

Icc Max

195mA

Packaging

Bulk

Power (dBm)

17

Manufacturer

Analog Devices Inc.

Package / Case

Module Adapter, SMA F (2)

Frequency Range

5GHz ~ 10GHz

Pushing (MHz/V)

0.2

Size / Dimension

1.390" L x 0.700" W (35.31mm x 17.78mm)

Voltage - Supply

12V

Frequency - Center

7.5GHz

Tuning Voltage (VDC)

0 V ~ 20 V

Operating Temperature

-40°C ~ 85°C

2nd Harmonic, Typ (dBc)

-15

Phase Noise Typ (dBc/Hz)

-64

Attribute	Value
Height	0.291" (7.38mm)
Series	-
Icc Max	195mA
Packaging	Bulk
Power (dBm)	17
Manufacturer	Analog Devices Inc.
Package / Case	Module Adapter, SMA F (2)
Frequency Range	5GHz ~ 10GHz
Pushing (MHz/V)	0.2
Size / Dimension	1.390" L x 0.700" W (35.31mm x 17.78mm)
Voltage - Supply	12V
Frequency - Center	7.5GHz
Tuning Voltage (VDC)	0 V ~ 20 V
Operating Temperature	-40°C ~ 85°C
2nd Harmonic, Typ (dBc)	-15
Phase Noise Typ (dBc/Hz)	-64
